Download and View
|
Instructions
Click any of the product listings below to expand and access associated diagrams, charts and specs.
Technical Information
Definitions, performance of friction material, braking process, torque calculation for an eccentric press & pneumatic scheme. DOWNLOAD
Clutch-Brake Series 5.8
Features maximum torque ratings per size. Up to 56,000 lb.ft. (77,000 Nm). DOWNLOAD
Clutch-Brake Series 5.7
Our most popular series, features 20% higher clutch torque. Up to 110,000 lb.ft. (150,000 Nm). DOWNLOAD
Clutch-Brake Series 5.0
Our original design. Up to 48,000 lb.ft. (66,000 Nm). DOWNLOAD
Clutch-Brake Series 5.5 & 5.6
Features multiple friction discs for highest torque vs. inertia and highest thermal capacity. Up to 101,000 lb.ft. (138,000 Nm). DOWNLOAD
Accessories
Air inlet disc, air rotary inlet & quick exhaust accessory. DOWNLOAD
Pneumatic Clutches Series 5.35
Multiple disc clutches. Torque up to 16,000 lb.ft. (22,000 Nm). DOWNLOAD
Pneumatic Safety Brakes
Series 5.36
Features spring engaged, pneumatic release braking. Up to 23,000 lb.ft. (33,000 Nm). DOWNLOAD
Pneumatic Safety Valves
MEP-A Redundant safety valves with inherent dynamic monitoring. Charts & specs. DOWNLOAD
Wet Clutch-Brake Series 5.W
Features oil cooling for longest service life. Up to 65,000 lb.ft. (89,000 Nm). DOWNLOAD
Special Clutch-Brake Units
Complete Press Drives
Every solution is a custom solution. Charts & specs. DOWNLOAD
Pneumatic Series 57 Manual
Mounting and maintenance instructions. DOWNLOAD
Pneumatic Series 58 Manual
Mounting and maintenance instructions. DOWNLOAD
Questionnaire
How to select your press. DOWNLOAD for Presses
DOWNLOAD for Applications
|
